Your clay printing Lab assistant.

3d clay printer.

The LUTUM® 5M is the only dedicated 3d clay printer with a stable and variable output, quick cartridge change, Hiwin mechanics, Igus chainlink + data cables and built from heavy 4mm thick powder coated and stainless steel parts for maximum print stability.
The LUTUM® 5M is the economical solution for small scale prototyping and laboratory work and was specifically developed for 3dclay development or production work for smaller items
This printer has all the printing qualities of its bigger brother but only has space for a single extruder. The Build volume is aproximately 25x25x40cm (LWH).

This machine will be available for delivery from Jule 2021.
Initially There will only be 10 units available of this specialized ‘little’ machine.

Assembled by hand and built for durability.

It’s our goal to give you the opportunity to expand the possibilities of crafting with clay. The LUTUM® 5M is an unmatched machine that can make this happen. It’s made from quality parts, and can easily cross current boundaries. We hope you can use it to think outside the box and run free with different kinds of clay.

While not losing sight of the outstanding build quality we give our products, we were able to significantly lower the construction cost of the LUTUM®5M. Not compromising on print quality and while keeping all the of the usability extras you can find in our bigger LUTUM 5 we were able to significantly reduce the production cost of thes smaller variant.

We are confident this machine will exceed expectations and will be very competative in the current market in terms of durability, 3dprint quality and customer support.

LUTUM 4 manufacture

Large integrated Touchscreen and Wi-Fi

This ceramics 3d printer is operated via an integrated Touchscreen and has an easy to understand menu structure to quickly give your machine the correct commands.

Your files (in .gcode format) can be transferred to the printer over Wi-fi using the browser enabled web interface.
The printer can be controlled from any internet capable device that connect to wifi or your local network.

Air supply and multi region power supply.

With your 3d clay printer you will receive a standard Warranty card, it is valid for at least 1 year.

The printer can operate with 230v or 110v. Above the air intake is a standard C14 male power socket.
You can give us your desired voltage after ordering your unit. It can always be changed if needed.

The printer supply air coupling is of the standard 14Ka male type (Orion).
You have to supply clean and dry air to this machine to operate correctly. The air pressure is needed to transport the clay into the extruder. You do not need a lot of air, the machine mainly uses the applied force.

A standard (low noise) compressor with a minimum of 8 Bar pressure, a storage capacity of 6 Liter, a moisture trap and a pressure regulator is the minimum requirement. it is highly recommeded to make sure the ‘kick-in’pressure of the machine is above 6 bar.
We normally do not supply a compressor with the printer as it will drive up the shipping cost significantly.
In virtually all instances it will be cheaper to find one locally.

4mm thick powder coated and Stainless Steel construction.

We use heavy powder coated steel in all our equipment to give the printer its excellent printing quality.
The 5 series has an extra layer of protection in the form of a 4mm thick Stainless Steel deck.

The heavy steel absorbs the vibration of the mechanical movements keeping your clay print still while printing layers upon it. This methode delivers the best print quality and enables you to print very delicate and fine structures not possible with other clay printer brands.

It is also euquipped with an internal 220v socket for connected machinery and can be equipped with an analog operation counter to officially logg maintenents events if that is mandatory bussiness practice within your organization.

The Unique Clay Extruder developed by VormVrij® 3D.

The LUTUM 5M 3dprinter is equipped with ou v10 316 stainless Steel extruder. It is very durable and can print a wide range of clay types with different viscosities.
It can handle grogg to a density of 25% at 0.2mm. All non electric parts can be simply cleaned with water and a brush.
becasue of the use of high pressure seals there is no need to clean the extruder in day to day use. Just park the tip in water and start printing the next day, or week.

High Quality, parts.

The LUTUM 5 uses high grade compnents troughout the machine. Compared to the 4 series is uses stringet drive motors, stronger bronze driver gear and wider belts on the axis.

The printer has a high speed 32bit processor and 32GB internal storage.
The 5M is also equipped with the infra red bed level compensation sensor for perfect clay deposition on any surface.
